48 Core Aerial Fiber Optic Splice Closure for Duct / Direct Buried
Description:
The optic fiber splice closures are widely apply for the connecting
of optical cable.
Fiber splice closure is used for aerial, strand-mount FTTH "tap"
locations where drop cables are spliced to distribution cables.
Fiber Optic Splice Closure is a fiber management product typically
used with outdoor fiber optical cables.
Optical splice closure provides space and protection for the fiber
optic cable splicing and joint.
Feature:
Suitable for ordinary fiber and ribbon fiber.
Easy to install and re-entry with a common can wrench.
Excellent Mechanical Sealed to protect fiber and splice ensuring
durability.
Stand up to severe condition of moisture,vibration and extreme
temperatures.
Fully kitted with all parts for convenient operation.
Overlap structure in splicing tray for easy installation.
Fiber-bending radium guaranteed more than 40mm.
Application:
It is belonged to open structure airproof tie-in system of machine
pressure.
It is used for the protective connection between two or more
optical cables.
It is widely used for communication, network system, CATV, the
fiber optic cable by network.
It is uitable for single core fiber optic cable and ribbon fiber
optic cable.
Main Technical Indexes:
Re-encapsulation performance: no change in the index of air-proof
performance after three times of repeat encapsulation
Airproof performance: Airing pressure inside box 100Kpa, pointer
immovability after 24 hours or no air bell within 15min when parked
in the common temperature water.
Specification:
| Type | FOSC-H001 | FOSC-H002 | FOSC-H003 | FOSC-H004 | FOSC-H005 | FOSC-H006 |
| Size(mm) | 435*190*85 | 435*190*120 | 435*190*120 | 435*190*80 | 435*190*170 | 420*150*110 |
| Cable diameter(mm) | Φ 10 – Φ 17 | Φ 10 – Φ 22 | Φ 10 – Φ 22 | Φ 10 – Φ 17 | Φ 10 – Φ 22 | Φ 10 – Φ 23 |
| Max capacity(core) | 96 | 168 | 192 | 96 | 288 | 96 |
| Cable port | 2 in, 2 out | 4 in, 4 out | 3 in, 3 out |
| Sealing structure | Sticky cincture |
| Weight(kg) | 2.6 | 2.8 | 2.6 | 2.3 | 4.7 | 2 |
Picture:
