LC / UPC 48 Cores Fiber Optic Patch Panel With Stainless Steel , 2u Patch Panel

LC / UPC 48 cores Fiber Optic Patch Panel with Stainless Steel

Description:

19inch,1U (2U, 3U),Rack mounting type.

Made of Cold Rolled Steel, with excellent performance of mechanical durability, anti-erosion, aging resistance and dustproof,flame-retardant.

The panel is easy to be pulled and pushed.

FC / SC / LC type,SC duplex adapters are adopted.

Capacity for 12/24/48/72/96/144 core is available.

Feature:

Environment temperature:-25℃~+45℃
Relative humidity:≤85%(30℃)
Atmosphere pressure:70~106KPa
Insulated Resistance:≥2×10MΩ/500V(DC)
Intensity≤15KV(DC)/1minno spark-over and no flying arc
Fiber bending radium guaranteed more than 40mm:≥40mm

Material: Cold rolled steel

High quality finish,without sharp edges.

With changeable panel for duplex or simplex adapter,easily combination with your real application.

Adoptable adapter types: FC, SC,LC/Duplex.

Application:

Introducing and fixing cables in wiring room and equipment room

Splicing and protection of optical fibers

Storage, connection and management of patch cords and pigtails

Telecommunications and CATV

FTTH, LANs and WANs

Specification:

Fixed Type:

Type	OTB-RF-1UA	OTB-RF-2UA	OTB-RF-1UB	OTB-RF-1UB	OTB-RF-1UC	OTB-RF-2UC
Size(mm)	4302501U	4302501U	4822951U	320240100	350340120	350340120
Max capacity(core)	24	48	24	48	24	48
Weight(kg)	2.6	3.8	3	4	3	5

Slidable Type:

Type	OTB-RS-1UA	OTB-RS-2UA	OTB-RS-1UB	OTB-RS-2UB	OTB-RS-1U-3MPO	OTB-RW-1U
Size(mm)	4303001U	4302502U	4822171U	4822172U	4822961U	4303001U
Max capacity(core)	24	48	24	48	36	24
Weight(kg)	3.5	4.0	3.5	4.0	3.0	4.7

Product Picture:
