3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance.

    Buy cheap 3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance. from wholesalers

    Buy cheap 3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance. from wholesalers
    • Buy cheap 3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance. from wholesalers
    • Buy cheap 3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance. from wholesalers

    3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance.

    Ask Lasest Price
    Brand Name : TTI OR OEM
    Model Number : SSC/upc-LC/upc Armoured fiber opitc patch cord
    Certification : ISO9001/ISO 14001 / ROHS
    Price : negotiate
    Payment Terms : T/T, , paypal, ,
    Supply Ability : 20000 pcs/month
    Delivery Time : 5-9 days
    • Product Details
    • Company Profile

    3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance.

    3.0mm Armoured Single model Fiber Jumpers With SC Upc LC Upc

    1. Description of Armored Single model fiber jumper:

    The 9/125 micron OS2 single mode fiber optic cable is suitable for higher bandwidth applications, such as in data centers, telecom rooms, server farms, cloud storage networks, and any place fiber jumper cables are needed. It meets RoHS compliant and cable is optically tested for insertion loss to ensure high quality.

    These armored fiber optic cables feature a built-in metal stainless steel tube to provide stronger protection of the optical fibers than standard fiber optic cables. The rugged armored cables allow optical fiber to be installed in the most hazardous areas, including environments with excessive dust, oil, gas, moisture, or even pesky rodents. Even though they are armored, a flexible 30mm bend radius and light-weight tubing makes them easy to install.

    2. Features:

    ♦ Duplex Fiber Count
    ♦ Available in 3 configurations - LC/LC, SC/SC, and LC/SC
    ♦ UPC to UPC Polish Type
    ♦ Quality zirconia ceramic ferrule ensures optimum IL and RL, giving you excellent performance.
    ♦ Industry standard flammability rating OFNR (Riser) jacket and duplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.
    ♦ 9/125µm fiber core and 3.0mm cable diameter provide maximum protection.
    ♦ Comprehensive performance testing makes sure the cables work more securely and data transmission more reliable and stable in your network.
    ♦ Constructed with a helical stainless steel tape over a buffered fiber surrounded by a layer of aramid and stainless steel mesh with an outer jacket.
    ♦ High tensile strength ≥100lbs."


    3. Application:


    Active device termination
    Instrumentation

    Telecommunication
    Computer networks
    CATV networks

    4. Specification:

    Connector TypeFC, SC, LC, ST, MU, MTRJ
    Fiber TypeSM(G.652D/G.657A)MM(OM1/OM2/OM3/OM4)
    Ferrule End-facePCUPCAPCUPC
    Insertion Loss≤0.2dB≤0.2dB≤0.3dB≤0.3bB
    Return Loss≥50dB≥55dB≥60dB≥35dB
    Exchangeability≤0.2dB
    Repeatability≤ 0.1dB(1000 times)
    Durability> 1000 times
    Operating Temperature-40°C ~ +85°C

    Fiber typeMin. BandwidthDistanceAttenuation
    62.5/125850/1300nm
    200/500 MHz/Km    		@100Mbps 2km @1Gig 220m850/1300nm
    3.0/1.0dB/km
    50/125850/1300nm
    500/500 MHz/Km    		@100Mbps 2km @1Gig 500m850/1300nm
    3.0/1.0dB/km
    50/125
    10Gig Optimized    		850/1300nm
    2000/500 MHz/Km    		@100Gig Varies by VCSEL typical 300m 2850nm850/1300nm
    3.0/1.0dB/km
    9/1251310/1550nm
    Approx 100 Terahertz    		Up to 100km Varies by transceiver1310/1550nm
    0.4/0.3dB/km

    5. Order Information:

    LC/UPC-SC/UPC-MM-DX-3.0mm-2M
    LC/UPC—SC/UPC/SM—SX/2.0—2M
    12324567
    1Connector#1: LC,SC,FC,ST, DIN, D4, MU,MTRJ,etc.
    2Lapping Way: UPC&APC (For MTRJ, F=Female, M=Male)
    3Connector#2: LC,SC,FC,ST,DIN,D4,MU,MTRJ,Pigtail,etc.
    4Cable Type: SM(9/125μm) ,MM(50/125μm & 62.5/125μm), OM3, OM4
    5Fiber Number: SX(Simplex) or DX(Duplex), 2/4/6/8 core...
    6Cable Diameter: 2.0=Ø2.0mm, 3.0=Ø3.0mm, 0.9=Ø0.9mm, etc.
    7Cable Length: 3m(Length in meter)

    Product Picture:
    SC Armoured Fiber Optical Patch Cord Multimode Duplex With Red / Black Boot 0SC Armoured Fiber Optical Patch Cord Multimode Duplex With Red / Black Boot 1

    Product Tags:

    Armoured Multimode Fiber Jumpers



    3.0mm Multimode Fiber Jumpers



    3.0mm Armoured fiber jumper cables


    Quality 3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance. for sale

    3.0mm Armoured steel Fiber Jumpers With SC Upc LC Upc excellent performance.
