G652D ADSS Aerial Fiber Optic Cable Self Supporting 24cores 100m Span

Ask Lasest Price
Brand Name :	TTI
Model Number :	ADSS
Certification :	ISO9001
Price :	0.3
Payment Terms :	L/C, D/A, D/P, T/T, , PayPal,
Supply Ability :	100000 PCS/Month
Delivery Time :	5-9 Days

Add to Cart

Product Details
Company Profile

G652D ADSS Aerial Fiber Optic Cable Self Supporting 24cores 100m Span

G652D ADSS All Dielectric 24cores 100m Span Self-Supporting Aerial
Fiber Optic Cable

ADSS Fiber Optic Cable
The fibers, 125μm, are positioned in a loose tube made of a high
modulus plastic.
The tubes are filled with a water-resistant filling compound.
A Fiber Reinforced Plastic (FRP) locates in the center of core as a
non-metallic strength member.
The tubes (and fillers) are stranded around the strength member
into a compact and circular core.
After the cable core is filled with the filling compound to protect
it from water ingress, the cable is completed with a PE sheath.

ADSS Fiber Optic Cable Feature:
Low attenuation and dispersion, special control of exceed length
ensure the good transmission performance in varying environment.
Excellent mechanical performance
Good flexibility and bending performance
Small outer diameter, lightness and compact construction

ADSS Fiber Optic Cable Optical Characteristics:
Item
G.652
G.655
50/125um
62.5/125um
Attenuation@850nm　　≤3.0dB/km≤3.2dB/km
@1300nm　　≤1.0dB/km≤1.2dB/km
@1310nm≤0.36dB/km≤0.40dB/km　　
@1550nm≤0.22dB/km≤0.23dB/km　　
Bandwidth
(Class A)@850nm　　≥500MHZ.km≥200MHZ.km
@1300nm　　≥1000MHZ.km≥600MHZ.km
Numerical aperture　　0.200±0.015NA0.275±0.015NA
Cable cut-off wavelength≤1260mm≤1450mm　　

Product Tags:

Self Supporting Aerial Fiber Optic Cable

G652D ADSS Fiber Optic Cable

100m Span 24 Core Fiber Cable

G652D ADSS Aerial Fiber Optic Cable Self Supporting 24cores 100m Span
